8×5 Tradesman Trailer with Brakes Tradie Trailer 2000kg ATM
- ATM: 2000 kg
- Tare: 500 kg
- Loading Capacity: 1500 kg
- Exterior Length: 4.30 m
- Exterior Width: 2.02 m
- Internal Size: 2420 x 1530 x 300 mm
- Drawbar: 1900 mm; 100 x 50 x 3 mm RHS
-
Coupling: 50 mm Over-ride Braked Coupling (ADR Standards)
- Safety Chain: 10mm with Hammerlock Shackle (a safe alternative to welding).
- Surface Finish: Hot Dipped Galvanised (Rust Free)
- Colour: Silver
-
Checker Plate: 2.5 mm
- Lights: LED Tail Lights + LED Number Plate Light + Side Lights
- Axle: Dual Axle, 50 mm Round Solid Axle (Front Disc Braked Axle)
-
Wheel & Tyres: 14” Sunraysia Steel Rims Ford Stud, 185/70R14C Light Truck Tyres
-
Jockey Wheel: 8” Swivel Heavy Duty 1500 lbs.
-
Sides: 300 mm Folded Up (Not Bolted)
-
Cage: 600 or 900 mm
-
Suspension: 6 Leaf (8mm) Rocker Roller Springs; Fully Welded Spring Hangers
– Improved Stability, Increased Load Capacity,
– Longer Lifespan & Better Handling
-
Brakes: 10″ Mechanical Disc Brake
- Warranty: 12 Months Structural
| Canopy Specifications (Customisable) |
- Height: 900mm
-
Material: 2.5 mm Marine Grade Aluminum Checker Plate 5052 Series
-
Doors: 2 or 3
-
Hinges: Full-Length Stainless Piano Hinge & Fully Rubber Sealed. Water Resistance and Dustproof
-
Roof Racks: Twin Roof Racks, Internal U-Channel & Box Section Braces
-
Roof Loading Capacity: 50kg Dynamic Loading Capacity on Roof
- Spare Wheel: $160
- Spare Wheel Holder: $60
- 12 Months VIC Registration: $150
- Toolbox 1200*400*360 mm: $550
- Galvanised Mower Pad: $500
More Features:
All of the electrical wirings have been passed interiorly through the chassis tubes, and therefore are not exposed.
Additionally, all of our trailers come with extra supports on the chassis, which makes our trailers exceptionally durable and safe.
- 50mm×50mm SHS Support Beams from Left to Right
- 40mm×40mm SHS Support Beams from Front to Back
If you have any questions or need assistance, please don’t hesitate to Contact Us.
